Adams Rite 8622LR-36 Exit Device

Adams Rite 8622LR-36 Exit Device

CVR Exit Device, Narrow Stile Aluminum Door, 36", Electric Latch Retraction, Dark Bronze

• Materials: Push bar made of extruded aluminum, cladded or anodized in a variety of finishes.
• Handing: Device is non-handed.
• Push bar Length: Standard sizes - dimensioned for 30", 36" , 42", and 48" openings. Standard width bars can be field cut to the next smallest opening width.
• Bar Height: Standard model adjusts from 30" to 44".
• Door Thickness: Suits 1-3/4" standard, up to 2-1/4". Device requires modification when used with cylinder in doors over 1-3/4". Please contact factory for more details.
• Door Height: Standard configuration suitable for doors up to 66" above the selected bar height. For doors over 66" above bar height, up to 10' use 8655 Tall Door Kit available separately.
• Stile Width: Minimum 2" stile. Fits narrow, medium, and wide stile aluminum doors.
• Stile Wall: Doors with stile walls other than 1/8" require modification.
• Projection: 2-5/8" when fully projected, 1-5/8" when dogged.
• Dogging: Standard dogging with hex key or optional cylinder dogging. Electric dogging option also available.
• Fasteners: Standard machine screws.
• Cylinders: Accepts any standard 1" length, 1-5/32" diameter mortise cylinder with MS® cam such as the 4036 Mortise Cylinder. Accommodates cylinder lengths from 1" to 1-1/4". Available separately.
• Cylinder x Fixed Pull Functions: For entry trim function 03 (Night latch - key releases latch) select any standard 1" length, 1-5/32" diameter mortise cylinder with MS® cam such as the 4036 Mortise Cylinder. Accepts any standard mortise cylinder with MS® cam. If key entry operation is required, any standard mortise cylinder with MS® cam can be installed through an 8650 Cylinder Escutcheon. 8650 Cylinder Escutcheon Kit available separately.
• Entry Trim Functions: For entry trim function 08 (key locks/unlocks lever) or function 09 (key releases lever) select any standard 1" length, 1-5/32" diameter mortise cylinder with MS® cam such as the 4036 Mortise Cylinder. Accommodates cylinder lengths from 1" to 1-1/4". Available separately.
• Bolts and Strikes: The patented top latching mechanism utilizes a rotating top bolt which deadlatches around the header strike, interlocking the door to the frame. Supplied with standard header strike. Adjustable protected steel rods. The hexagonal, hardened steel bottom bolt is shielded in a cast housing for strength and stability.
• Standard Package: Individually boxed.
• Shipping Weight: 12 lbs
