Alarm Controls AES-200 Electric Strike

Alarm Controls AES-200 Electric Strike

Grade 2 Dual Voltage Electric Strike with Monitoring, 1-1/2in Depth, Field Selectable Fail Secure/Fail Safe Operation. Accommodates 5/8in Throw Cylindrical Locksets. Includes Two 4-7/8in Stainless Steel Face Plates (One Round Corner & One Square Corner.)

• BHMA Grade 2
• 1000 lb. static strength
• Factory cycle tested to 500,000 cycles
• Strike depth 1-1/2"
• 5/8" throw
• Adjustable keeper
• Strike monitored with SPDT (1 form C), dry contacts
• Field selectable, fail safe/fail secure
• Universal 12 through 24VAC or VDC input
• Fully reversible for right or left hand doors
• Mounting kit includes two 4-7/8" stainless steel face plates (one round corner and one square corner)
• Horizontally adjustable, pre-load capable
• Built-in buzzer, sounds when voltage is applied
• Current draw 12 VAC 200mA, 24 VAC 70mA
• Current draw 12 VDC 130mA, 24 VDC 70mA
• 7-7/16" round corner strike plate available. Model number STR00004
