Altronix AL600ULX Power Supply

• Input:
• Input 115VAC, 60Hz, 3.5 amp.
• Output:
• 12VDC or 24VDC selectable output.
• 6 amp continuous supply current.
• Filtered and electronically regulated output.
• Short circuit and thermal overload protection.
• Battery Backup:
• Built-in charger for sealed lead acid or gel type batteries.
• Automatic switch over to stand-by battery when AC fails.
• Maximum charge current 0.7 amp.
• Supervision:
• AC fail supervision (form "C" contacts).
• Notification trigger is selectable for 30 seconds (factory set) or 6 hours.
• Low battery supervision (form "C" contacts).
• Battery presence supervision (form "C" contacts).
• Visual Indicators:
• AC input and DC output LED indicators.
• Electrical:
• Operating temperature: 0° C to 49° C ambient.
• 36.85 or 73.70 BTU/Hr.
• System AC input VA requirement: 402.5VA.
• Mechanical:
• Enclosure Dimensions (H x W x D approx.): 13.5" x 13" x 3.25" (342.9mm x 330.2mm x 82.55mm)
• Accommodates up to two (2) 12VDC/7AH batteries.
• Product weight (approx.): 7.6 lbs. (3.45 kg).
• Shipping weight (approx.): 8.5 lbs. (3.86 kg).
