Altronix SAV182D Power Supply

Altronix SAV182D Power Supply

Sav182D Power Supply provides 12VDC distributed via eighteen (18) Class 2 Rated PTC protected power limited outputs for powering surveillance cameras.

• Input:
• 115VAC 60Hz, 3 amp /230VAC 50Hz, 1.5 amp.
• Output:
• 12VDC @ 11 amp total output current (0.61 amp per device, 2.5 amp max.).
• Eighteen (18) Class 2 Rated PTC protected power-limited outputs.
• Filtered and electronically regulated outputs.
• Short circuit and thermal overload protection.
• Electrical:
• Operating temperature: 0° C to 49° C ambient.
• 68.24 BTU/Hr.
• System AC input VA requirement:
• 115VAC: 345VA.
• 230VAC: 330VA.
• Features:
• Eighteen (18) power LEDs.
• Field installable 3-wire line cord with integral strain relief.
• Unit maintains camera synchronization.
• Ease of installation saves time and eliminates costly labor.
• Mechanical:
• NEMA1 enclosure.
• Enclosure Dimensions (H x W x D approx.): 13.5" x 13" x 3.25" (342.9mm x 330.2mm x 82.55mm)
• Product weight (approx.): 7.8 lbs. (3.54 kg).
• Shipping weight (approx.): 8.7 lbs. (3.95 kg).
