BEA 10PIEZO241 Pushbutton

BEA 10PIEZO241 Pushbutton

Piezo Button, Single Gang, for Request to Exit and Access Control Packages, 1 to 40 Second, User-Adjustable Output Hold Time, Heavy Duty Construction, 12/24 VDC Auto-Sensing

• Heavy Duty Construction
• The Piezo Button incorporates piezoelectric technology to convert physical touch (pressure) of the push button from mechanical to electrical energy
• Status illumination can be set to red, green, or no illumination
• Selectable Fail Safe and Fail Secure options
• Hold timer lasts from as little as 1 second to as much as 40 seconds
• The Piezo button provides for a NO / NC contact
• Stainless steel construction is designed for all weather use
• Designed specifically for Request to Exit / access control applications
• Button switch life exceeds one billion cycles
• Compatible with most single gang boxes
• Voltage Input 12-24 VDC
• Hold Time 1-40 Seconds
• Current: LEDs On: 40 mA (Idle), 60mA (Active) // LEDs Off : 10 mA (Idle), 40mA (Active)
• Plastic Transparent Light Ring
• Dimensions 2.75" x 4.5" x 1.25" 3/8" cut corners
• Weight 8.0 oz (220 g)
