Attributes
Ship via: Can Ship UPS
Alternate Codes: 45H7-T-15J-626, 45H7T15J-626, 45H7T15J626, BES45H7T15J-626, BES45H7T15J626-LHR
Ansi Function: F13 - Dormitory
Ansi Function Description: Entry/Office
Baa Qualified: Yes
Backset: 2-3/4"
Bolt Protection: 3/4" Latch, 1" Deadbolt
Case Dimensions: 5-7/8" x 4-1/16"
Country of Origin: Usa
Cylinder Included: No
Cylinder Type: IC Core Cylinder, Mortise Cylinder
Cylinders Present: Single Cylinder
Door Bore Size: 2-1/8"
Door Thickness: 1-3/4"
Door Thickness Min: 1-3/4"
Dust Box: Plastic
Finish: 626/US26D
Finish Color: Satin Chrome
Finish Description: Satin Chrome
Fire Rated: 3 Hours {A}
Function: T-Dormitory
Function Family: Corridor/Dormitory
Grade: Grade 1
Hand: Field Reversible
Handing: Field Reversible
Knob/ Lever Design: 15
Knob/ Lever Style: Lever
Latch Backset Dim: 2-3/4"
Latch Bolt Face Type: Square Corner
Latch Bolt Faceplate Size: 8" x 1-1/4"
Latch Bolt Throw: 3/4"
Latch Bolt Type: Deadlatch
Latch Number: 45H
Latch Type: Faceplate
Lever Knob: Lever
Lever Knob Design: 15 - Lever
Lever Knob Design Family: Straight Return Lever
Lever Knob Design Name: 15
Limited Warranty: Limited Lifetime
Lock Category: Mortise Lock
Lock Face Size: 8" x 1-1/4"
Manufacturer Function: Dormitory
Manufacturer Function Description: Operated by rotating inside lever, rotating outside lever - only when deadbolt is retracted, turning key in outside cylinder.
Maximum Door Thickness: 1-3/4"
Minimum Door Thickness: 1-3/4"
Num Pins: 7
Pocket Dimensions: 6-5/8" x 4-1/4"
Projection: 2-15/16"
Rose Escutcheon: Escutcheon
Rose Escutcheon Design: J - Escutcheon
Rose Escutcheon Dimensions: 2-9/32" x 7-1/2"
Rose/ Escutcheon Size: 7-1/2" H x 2-9/32" x 17/32"
Rose/ Escutcheon Style: Escutcheon
Screws: Combination
Series: 40H Series
Strike Dimensions: 1-1/4" x 4-7/8"
Strike Height: 4-7/8"
Strike Number: 40HST1
Strike Size: 4-7/8" x 1-1/4"
Strike Type: ASA
Strike Width: 1-1/4"
Structure Cylinder: 7
Structure Function: T
Structure Latch Number: 45H
Structure Outside Finish: 626
Structure Outside Rose: J
Structure Outside Trim: 15
Structure Series: 45H
Structure Strike Number: ANSI
Subtype: Mortise Lock
Supplier: Best Access
Type: LOCK SETS
