Corbin Russwin ML2030-LL-626 Mortise Lock

Corbin Russwin ML2030-LL-626 Mortise Lock

Corbin ML2030LL626 F19 Privacy Mortise Lever by Lever Lock Body, Strike, Front Plate, and Screws Satin Chrome Finish

• Handing: Handed quick reversible. The lockset can be re-handed without disassembling the lock case
• Backset 2-3/4" (70mm)
• Lockcase: Heavy-gauge steel, 5-7/8" (149mm) x 4" (102mm) x 15/16" (24mm)
• Optional: non-ferrous lockcase for corrosion resistance; see Quick Codes
• Front: Heavy-gauge steel, 8" (203mm) x 1-1/4" (32mm) x -3/32" (2mm). Accommodates flat doors and doors beveled 1/8" (3mm) in 2" (51mm). Furnished 1-1/16" (27mm), optional D138, wide for 1-3/8" (35mm) doors
• Armored Front: Wrought brass, bronze or stainless steel attached by machine screws to lockcase front. ML2000HS & ML2000VR utilizes security Torx® screws.
• Latchbolt: 2-piece mechanical with anti-friction insert, 5/8" (16mm) x 1" (25mm) x 3/4" (19mm) throw.
• Auxiliary Latchbolt: 9/16" (14mm) effective throw and 3/8" (10mm) effective auxiliary latch deadlocking.
• Deadbolt: One-piece stainless steel, 19/32" (15mm) x 1-1/4" (32mm) x 1" (25mm) throw.
• Occupancy Indicator: Occupancy indicators for use with ML2000 x sectional trim. Design features option for dual indicators on double cylinder functions, confirming door is secured from either side. Emergency override standard for all non-keyed functions.
• Hub
• Knob: stainless steel, 9/32" (7mm) x 9/32" (7mm). 3/8" (10mm) stainless steel.
• Lever: steel, 5/16" (8mm).
• Spacing:
• C. to c. knob/lever to cylinder: 3-5/8" (92mm).
• C. to c. knob/lever to thumbturn: 2-7/16" (62mm).
• Strike: Wrought brass, bronze or stainless steel, ANSI straight lip standard, 4-7/8" (124mm) x 1-1/4" (32mm) x 1-1/8" (29mm) lip to center. Optional strikes, lip lengths and ANSI wrought strike box available
• Patented Quick Reversible feature enables reversal of hands without disassembling the lock case (Patent # 6,349,982)
• Security trims provide a vandal-resistant barrier
• Can be used with new or existing Corbin Russwin key systems, including patented high-security Pyramid cylinders. (Patent # 6,125,674) Also accepts cylinders of most other manufacturers.
• Provides life safety and security in a single door prep, saving the additional cost of a deadlock
• Through-bolted trim designs for proper alignment and increased security
