Richelieu 2716647100 FREEflap Forte Opening SystemPractical, balanced and compact, FREEflap is the "little toughie" in the lifter family. The integrated multi-position-stop guarantees that the front will stop securely in any position.
Advantages and benefits
- Minimum installation depth (118 mm)
- Generates 27 kg lift force
- 90º & 107º opening angles
- Soft and fluid movement
- Multi-position stop
- German Design Award Special Mention 2015
- Compact design, easy assembly
Important information
- Total opening angle: 107º
- 90º opening angle limiter integrated into the fitting
* Support for aluminum frame sold separately.
Included products
- 2 Freeflap forte fittings (right and left)
- 2 Dress caps for fittings (right and left)
- 2 Door connector plates
- Drilling template
Attributes
Ship via: Can Ship UPS
Brand: Richelieu
Door Height: 400 to 600 mm
Finish: Gray
Max weight for door height <= to 350 mm: 5.2 to 11 kg
Max weight for door height <= to 375 mm: 4.9 to 10.2 kg
Max weight for door height <= to 400 mm: 4.7 to 9.6 kg
Max weight for door height <= to 425 mm: 4.4 to 9 kg
Max weight for door height <= to 450 mm: 4.1 to 8.4 kg
Max weight for door height <= to 475 mm: 3.9 to 8 kg
Max weight for door height <= to 500 mm: 3.7 to 7.5 kg
Max weight for door height <= to 525 mm: 3.5 to 7.1 kg
Max weight for door height <= to 550 mm: 3.3 to 6.8 kg
Max weight for door height <= to 575 mm: 3.2 to 6.5 kg
Max weight for door height <= to 600 mm: 3 to 6.2 kg
Max weight for door height <= to 625 mm: 2.8 to 5.9 kg
Max weight for door height <= to 650 mm: 2.6 to 5.6 kg
Opening Angle: 107°
Opening Types NEW: Lift-Up Opening
Power Factor: 1 880 to 3 040
Product number: 2716647100
Product №: 2716647100
System Name: D
System Type: Soft-Close
Unit: Box
Unit 1: skid - 152
Unit 2: skid - 152
